05.07.2026 | Actuators & Air Consumption

Understand actuator types and how to choose the right solution for your application. This guide explains electric, pneumatic, diaphragm and piston actuators, how they work, and key factors like torque, performance and use cases across industries including HVAC and modern data center cooling systems. The guide also includes a downloadable technical PDF for detailed actuator sizing and selection guidance.

This guide covers:

What Is an Actuator?

An actuator is a device that converts energy into mechanical motion to control the position of a valve or damper. In flow control systems, actuators are used to open, close or modulate valves, enabling precise control of liquids or gases.

Actuators are typically powered by:

  • Electricity (electric actuators)
  • Compressed air (pneumatic, diaphragm and piston actuators)

Choosing the right actuator ensures reliable operation, accurate control and long term system performance.

Actuator Types Chart: Electric vs Pneumatic vs Diaphragm vs Piston

Type Power Source Motion Type Key Benefit Best For
Electric Electricity Rotary/Linear High precision Automation & control systems
Pneumatic Compressed air Rotary/Linear Fast response Industrial automation
Diaphragm Air pressure Rotary/Linear Precise modulation Control valves
Piston Air pressure Rotary/Linear High force output Heavy duty applications

Different Types Explained

Each actuator type offers distinct performance characteristics depending on application requirements, operating conditions and system constraints.

  • Electric actuators are ideal for precision and automation, offering accurate positioning and seamless integration with control systems.
  • Pneumatic actuators are known for fast response, durability and high cycle capability, making them a common choice in industrial environments.
  • Diaphragm actuators provide smooth, stable linear motion and are typically used in modulating control valve applications where accuracy is critical.
  • Piston actuators deliver higher output force and are well suited for high pressure systems or larger valves requiring greater torque.

How Each Type of Actuator Works

Electric Actuators:

Electric actuators use a geared motor to generate torque, converting electrical energy into rotary or linear motion. They are controlled via electrical signals, allowing precise and repeatable positioning.

Pneumatic Actuators:

Pneumatic actuators use compressed air to generate motion. Air pressure drives internal components to open or close the valve, enabling fast actuation and reliable performance in high cycle applications.

Diaphragm Actuators:

Diaphragm actuators use air pressure applied to a flexible diaphragm to create linear motion. This allows for stable and accurate valve positioning, particularly in throttling or modulating service.

Piston Actuators:

Piston actuators use compressed air to move a piston within a cylinder, generating higher force output. This design is suited for demanding applications requiring increased torque or pressure resistance.

When to Use Each Actuator

When selecting an actuator, consider the following key factors:

Power Source & Compatibility

The availability of electrical power or compressed air is a primary consideration in actuator selection.

Torque Requirements

Actuators must provide sufficient torque to operate and seat the valve under all operating conditions.

Failure Mode

Applications may require fail-open, fail-closed, or fail-in-place operation, which can influence actuator type selection.

Speed & Duty Cycle

Pneumatic actuators are well suited for high cycle operation, while electric actuators may be limited by duty cycle and motor constraints.

Environment

Operating conditions such as temperature, hazardous areas and moisture exposure must be considered when selecting an actuator.

Maintenance & System Costs

System complexity, maintenance requirements and total cost of ownership should be evaluated.

Real World Applications by Type

Industry Recommended Actuator Type
HVAC, Building Systems & Data Centers Electric or Pneumatic
Oil & Gas Pneumatic or Piston
Chemical Processing Diaphragm or Pneumatic
Food & Beverage / Pharmaceutical Diaphragm or Electric
Heavy Industry Piston

Each application requires a balance of control, durability and force depending on system demands.

Actuators in Data Center Cooling Systems

Modern data centers rely heavily on actuated valves within cooling infrastructure to maintain temperature control, energy efficiency and system uptime.

Actuators are commonly used in:

  • Chilled water systems
  • Cooling towers
  • CRAC and CRAH units
  • Liquid cooling systems

Electric actuators are especially common in data center environments due to their precise control, energy efficiency and seamless integration with Building Management Systems (BMS).

Typical valve applications include:

  • Modulating control valves for chilled water regulation
  • Butterfly valves for large diameter piping systems
  • Ball valves for isolation and shutoff
  • Pressure Independent Control Valves (PICVs) for precise flow control

As data centers continue to expand alongside AI and high performance computing demands, smart actuator technology is becoming increasingly important for maintaining reliable and efficient cooling performance.

How to Choose the Right Actuator

The right actuator depends on your specific application requirements.

  • Choose electric actuators for precision and automation.
  • Choose pneumatic actuators for speed and reliability.
  • Choose diaphragm actuators for accurate flow control.
  • Choose piston actuators for high force applications.

Actuator selection should also account for torque sizing, safety factors and process conditions, which can significantly impact long term performance and reliability. For most industrial systems, pneumatic or electric actuators provide a strong balance of performance and efficiency. However, specialized environments may require diaphragm or piston designs.

With growing demand for energy efficient HVAC infrastructure and liquid cooled data centers, electric actuator technology continues to play a critical role in modern automated flow control systems.

Need a more detailed selection guide?

For a deeper technical breakdown of actuator selection, including torque requirements, safety factors, failure modes, and performance characteristics, download our full guide.

Still looking for the right actuator? Contact SVF experts or explore our full range of actuators.
